Spec Dossier
The Blueprint
// SYS_SPECS: VERIFIED
| Backplate | Included, aluminium |
|---|---|
| Cold Plate | Full-cover copper, nickel-plated |
| Dimensions | 235 x 145 x 28 mm |
| Fin Structure | 0.4 mm micro-channel |
| GPU Support | RTX 5090 / 5080, reference PCB |
| Ports | G1/4 (4, rotatable terminal) |
| Top Material | Cast acrylic |
| Weight | 1,240 g |
| Box Contents | CGP Forge GPU waterblock Aluminium backplate with mounting screws Thermal pads for memory and VRM 5V ARGB cable Installation guide and warranty card |
| Warranty | 3 years |
| Compatibility | Fits RTX 5090 and RTX 5080 cards on the reference PCB · custom layouts need a fitment check with our team |
// PRICE BREAKDOWN
SYS_PART
CGP Forge GPU Waterblock — Full-Cover Acrylic
1,099.00
SHIPPING
Free — ships from Riyadh in 3-5 days
WARRANTY
3 years
TOTAL
1,099.00// THERMAL TELEMETRY
Thermal telemetry: idle 38°C, sustained load 64°C — verified on the bench.
// IDLE
38°C
// LOAD
64°C
The Story
The hardest part of covering a modern graphics card is not the water path — it is the weight. A plate long enough to sit over core, memory and VRM also acts as a lever on a PCB that was never designed to carry it. The CGP Forge design answers with a machined copper body, 0.4 mm micro-channels across the full contact area, and a mounting pattern that loads the board evenly instead of at the ends.The acrylic top stays clear so the fin field can be inspected, and the aluminium backplate is not decoration: it stiffens the assembly and carries half the clamping load off the card. Four ports sit in a rotatable terminal, so routing stays clean in tight cases. Before sign-off, every block is held at 1.5 bar for 30 minutes, then bolted to a reference card and checked for PCB flex.
The Dossier
Forged & Verified
// SYS_VERIFIED
// THE FORGE LOG
- 11 JUL 2026 MACHINING copper plate milled to the full-cover profile, 0.4 mm channels cut
- 16 JUL 2026 ASSEMBLY acrylic top and aluminium backplate fitted, terminal set for standard routing
- 21 JUL 2026 PRESSURE TEST 1.5 bar held for 30 minutes, no drop at the four-port terminal
- 26 JUL 2026 QA SIGN-OFF block bolted to a reference PCB, contact pattern confirmed flat
// PROVENANCE
Made in Riyadh, where the copper body is machined and the terminal is assembled and sealed by hand. Each unit ships with a serial etch, a signed pressure-test record and the contact pattern photographed on a reference board. Three checks, one signature, no exceptions.
