CGP Forge PETG Tubing 14mm — 4-Pack

Spec Dossier

The Blueprint

// SYS_SPECS: VERIFIED

CGP Forge PETG Tubing 14mm — 4-Pack — full specification dossier
Bend Radius35 mm minimum
FinishMirror-polished, scratch-resistant
Inner Diameter10 mm
Length4 x 1,000 mm
MaterialPETG
Max Operating Temp60 °C
Outer Diameter14 mm
Wall Thickness2 mm
Box Contents4 x CGP Forge PETG tubes, 14 mm OD and 10 mm ID, 1,000 mm each Silicone bending insert Cutting and deburring tool Bend radius template Installation guide and warranty card
Warranty1 year
CompatibilityCGP Forge compression fittings for 14 mm OD hardline · bends down to a 35 mm radius · keep coolant at or below 60 °C

// PRICE BREAKDOWN

SYS_PART CGP Forge PETG Tubing 14mm — 4-Pack
 149.00
SHIPPING Free — ships from Riyadh in 3-5 days
WARRANTY 1 year
TOTAL
 149.00

The Story

A hardline run is designed around one number: how far a tube can turn before it fails. PETG bends without the hazing that shows up in cheaper acrylic, and this tube holds a 35 mm minimum radius — tight enough to clear a pump top or a memory stick without a fitting on every corner. Get that radius right and a run can be planned, cut and rebuilt from a drawing instead of guesswork.The wall is 2 mm, which keeps the inner bore at 10 mm — the same flow area as our flexible runs, so switching to hardline costs nothing in pump performance. Each tube arrives cut to 1,000 mm with both ends chamfered, then polished until the surface reads like glass; a scratch-free tube seats deeper into a compression collar and seals on the first turn. Four tubes per pack cover a CPU and GPU loop with enough left for a mistake.

The Dossier

Forged & Verified

// SYS_VERIFIED

// THE FORGE LOG

  1. 14 AUG 2026 MACHINING PETG extruded to 14 mm OD and 10 mm ID, wall thickness checked every 10 metres
  2. 20 AUG 2026 ASSEMBLY tubes cut to 1,000 mm and ends chamfered, four pieces bundled per pack
  3. 24 AUG 2026 PRESSURE TEST sample bent to the 35 mm minimum radius and held at 1.5 bar
  4. 29 AUG 2026 QA SIGN-OFF surface polished and inspected for crazing under light, pack sealed

// PROVENANCE

Extruded and finished in Riyadh from PETG stock that is checked for diameter drift before it is cut. Each pack is bundled by hand, and one tube per batch is bent to the minimum radius and pressure-tested so the rest of the run can be trusted. The batch number is printed on the protective sleeve.
